DeviceBatchedGemm_Wmma_CShuffleV3< ALayout, BLayout, CLayout, ADataType, BDataType, CDataType, AccDataType, CShuffleDataType, AElementwiseOperation, BElementwiseOperation, CElementwiseOperation, GemmSpec, BlockSize, MPerBlock, NPerBlock, KPerBlock, AK1, BK1, MPerWmma, NPerWmma, MRepeat, NRepeat, ABlockTransferThreadClusterLengths_AK0_M_AK1, ABlockTransferThreadClusterArrangeOrder, ABlockTransferSrcAccessOrder, ABlockTransferSrcVectorDim, ABlockTransferSrcScalarPerVector, ABlockTransferDstScalarPerVector_AK1, ABlockLdsExtraM, BBlockTransferThreadClusterLengths_BK0_N_BK1, BBlockTransferThreadClusterArrangeOrder, BBlockTransferSrcAccessOrder, BBlockTransferSrcVectorDim, BBlockTransferSrcScalarPerVector, BBlockTransferDstScalarPerVector_BK1, BBlockLdsExtraN, CShuffleMRepeatPerShuffle, CShuffleNRepeatPerShuffle, CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock, CShuffleBlockTransferScalarPerVector_NPerBlock, BlkGemmPipeSched, BlkGemmPipelineVer, ComputeTypeA, ComputeTypeB, PermuteA, PermuteB > Struct Template Reference#
Classes |
Public Types |
Public Member Functions |
Static Public Member Functions |
List of all members
ck::tensor_operation::device::DeviceBatchedGemm_Wmma_CShuffleV3< ALayout, BLayout, CLayout, ADataType, BDataType, CDataType, AccDataType, CShuffleDataType, AElementwiseOperation, BElementwiseOperation, CElementwiseOperation, GemmSpec, BlockSize, MPerBlock, NPerBlock, KPerBlock, AK1, BK1, MPerWmma, NPerWmma, MRepeat, NRepeat, ABlockTransferThreadClusterLengths_AK0_M_AK1, ABlockTransferThreadClusterArrangeOrder, ABlockTransferSrcAccessOrder, ABlockTransferSrcVectorDim, ABlockTransferSrcScalarPerVector, ABlockTransferDstScalarPerVector_AK1, ABlockLdsExtraM, BBlockTransferThreadClusterLengths_BK0_N_BK1, BBlockTransferThreadClusterArrangeOrder, BBlockTransferSrcAccessOrder, BBlockTransferSrcVectorDim, BBlockTransferSrcScalarPerVector, BBlockTransferDstScalarPerVector_BK1, BBlockLdsExtraN, CShuffleMRepeatPerShuffle, CShuffleNRepeatPerShuffle, CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock, CShuffleBlockTransferScalarPerVector_NPerBlock, BlkGemmPipeSched, BlkGemmPipelineVer, ComputeTypeA, ComputeTypeB, PermuteA, PermuteB > Struct Template Reference
"Universal" Batched GEMM operation without SplitK support. More...
#include <device_batched_gemm_wmma_cshuffle_v3.hpp>
Inheritance diagram for ck::tensor_operation::device::DeviceBatchedGemm_Wmma_CShuffleV3< ALayout, BLayout, CLayout, ADataType, BDataType, CDataType, AccDataType, CShuffleDataType, AElementwiseOperation, BElementwiseOperation, CElementwiseOperation, GemmSpec, BlockSize, MPerBlock, NPerBlock, KPerBlock, AK1, BK1, MPerWmma, NPerWmma, MRepeat, NRepeat, ABlockTransferThreadClusterLengths_AK0_M_AK1, ABlockTransferThreadClusterArrangeOrder, ABlockTransferSrcAccessOrder, ABlockTransferSrcVectorDim, ABlockTransferSrcScalarPerVector, ABlockTransferDstScalarPerVector_AK1, ABlockLdsExtraM, BBlockTransferThreadClusterLengths_BK0_N_BK1, BBlockTransferThreadClusterArrangeOrder, BBlockTransferSrcAccessOrder, BBlockTransferSrcVectorDim, BBlockTransferSrcScalarPerVector, BBlockTransferDstScalarPerVector_BK1, BBlockLdsExtraN, CShuffleMRepeatPerShuffle, CShuffleNRepeatPerShuffle, CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock, CShuffleBlockTransferScalarPerVector_NPerBlock, BlkGemmPipeSched, BlkGemmPipelineVer, ComputeTypeA, ComputeTypeB, PermuteA, PermuteB >:
Classes | |
| struct | Argument |
| struct | ComputePtrOffsetOfStridedBatch |
| struct | Invoker |
| Helper structure responsible for kernel invocation. More... | |
Public Types | |
| using | GridwiseGemm = GridwiseGemm_wmma_cshuffle_v3< ALayout, BLayout, CLayout, ADataType, BDataType, AccDataType, CShuffleDataType, CDataType, AElementwiseOperation, BElementwiseOperation, CElementwiseOperation, GemmSpec, BlockSize, MPerBlock, NPerBlock, KPerBlock, AK1, BK1, MPerWmma, NPerWmma, MRepeat, NRepeat, ABlockTransferThreadClusterLengths_AK0_M_AK1, ABlockTransferThreadClusterArrangeOrder, ABlockTransferSrcAccessOrder, ABlockTransferSrcVectorDim, ABlockTransferSrcScalarPerVector, ABlockTransferDstScalarPerVector_AK1, false, ABlockLdsExtraM, BBlockTransferThreadClusterLengths_BK0_N_BK1, BBlockTransferThreadClusterArrangeOrder, BBlockTransferSrcAccessOrder, BBlockTransferSrcVectorDim, BBlockTransferSrcScalarPerVector, BBlockTransferDstScalarPerVector_BK1, false, BBlockLdsExtraN, CShuffleMRepeatPerShuffle, CShuffleNRepeatPerShuffle, CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock, CShuffleBlockTransferScalarPerVector_NPerBlock, BlkGemmPipeSched, BlkGemmPipelineVer, ComputeTypeA, ComputeTypeB, false, false > |
Public Member Functions | |
| bool | IsSupportedArgument (const BaseArgument *p_arg) override |
| std::unique_ptr< BaseArgument > | MakeArgumentPointer (const void *p_a, const void *p_b, void *p_c, index_t M, index_t N, index_t K, index_t StrideA, index_t StrideB, index_t StrideC, index_t BatchStrideA, index_t BatchStrideB, index_t BatchStrideC, index_t Batch, AElementwiseOperation, BElementwiseOperation, CElementwiseOperation) override |
| std::unique_ptr< BaseInvoker > | MakeInvokerPointer () override |
| std::string | GetTypeString () const override |
 Public Member Functions inherited from ck::tensor_operation::device::BaseOperator | |
| BaseOperator ()=default | |
| BaseOperator (const BaseOperator &)=default | |
| BaseOperator & | operator= (const BaseOperator &)=default |
| virtual std::string | GetTypeIdName () const |
| virtual std::optional< std::string > | GetObjectName () const |
| virtual std::optional< std::string > | GetTemplateInfo () const |
| virtual std::string | GetTypeIdHashCode () const |
| virtual size_t | GetWorkSpaceSize (const BaseArgument *) const |
| virtual void | SetWorkSpacePointer (BaseArgument *p_arg, void *p_workspace, const StreamConfig &=StreamConfig{}) const |
| virtual | ~BaseOperator () |
Static Public Member Functions | |
| static constexpr bool | IsValidCompilationParameter () |
| static bool | IsSupportedArgument (const Argument &arg) |
| static auto | MakeArgument (const ADataType *p_a, const BDataType *p_b, CDataType *p_c, index_t M, index_t N, index_t K, index_t StrideA, index_t StrideB, index_t StrideC, index_t BatchStrideA, index_t BatchStrideB, index_t BatchStrideC, index_t Batch, AElementwiseOperation, BElementwiseOperation, CElementwiseOperation) |
| static auto | MakeInvoker () |
Detailed Description
template<typename ALayout, typename BLayout, typename CLayout, typename ADataType, typename BDataType, typename CDataType, typename AccDataType, typename CShuffleDataType, typename AElementwiseOperation, typename BElementwiseOperation, typename CElementwiseOperation, GemmSpecialization GemmSpec, index_t BlockSize, index_t MPerBlock, index_t NPerBlock, index_t KPerBlock, index_t AK1, index_t BK1, index_t MPerWmma, index_t NPerWmma, index_t MRepeat, index_t NRepeat, typename ABlockTransferThreadClusterLengths_AK0_M_AK1, typename ABlockTransferThreadClusterArrangeOrder, typename ABlockTransferSrcAccessOrder, index_t ABlockTransferSrcVectorDim, index_t ABlockTransferSrcScalarPerVector, index_t ABlockTransferDstScalarPerVector_AK1, bool ABlockLdsExtraM, typename BBlockTransferThreadClusterLengths_BK0_N_BK1, typename BBlockTransferThreadClusterArrangeOrder, typename BBlockTransferSrcAccessOrder, index_t BBlockTransferSrcVectorDim, index_t BBlockTransferSrcScalarPerVector, index_t BBlockTransferDstScalarPerVector_BK1, bool BBlockLdsExtraN, index_t CShuffleMRepeatPerShuffle, index_t CShuffleNRepeatPerShuffle, typename CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock, index_t CShuffleBlockTransferScalarPerVector_NPerBlock, BlockGemmPipelineScheduler BlkGemmPipeSched = BlockGemmPipelineScheduler::Intrawave, BlockGemmPipelineVersion BlkGemmPipelineVer = BlockGemmPipelineVersion::v1, typename ComputeTypeA = CDataType, typename ComputeTypeB = ComputeTypeA, bool PermuteA = false, bool PermuteB = false>
struct ck::tensor_operation::device::DeviceBatchedGemm_Wmma_CShuffleV3< ALayout, BLayout, CLayout, ADataType, BDataType, CDataType, AccDataType, CShuffleDataType, AElementwiseOperation, BElementwiseOperation, CElementwiseOperation, GemmSpec, BlockSize, MPerBlock, NPerBlock, KPerBlock, AK1, BK1, MPerWmma, NPerWmma, MRepeat, NRepeat, ABlockTransferThreadClusterLengths_AK0_M_AK1, ABlockTransferThreadClusterArrangeOrder, ABlockTransferSrcAccessOrder, ABlockTransferSrcVectorDim, ABlockTransferSrcScalarPerVector, ABlockTransferDstScalarPerVector_AK1, ABlockLdsExtraM, BBlockTransferThreadClusterLengths_BK0_N_BK1, BBlockTransferThreadClusterArrangeOrder, BBlockTransferSrcAccessOrder, BBlockTransferSrcVectorDim, BBlockTransferSrcScalarPerVector, BBlockTransferDstScalarPerVector_BK1, BBlockLdsExtraN, CShuffleMRepeatPerShuffle, CShuffleNRepeatPerShuffle, CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock, CShuffleBlockTransferScalarPerVector_NPerBlock, BlkGemmPipeSched, BlkGemmPipelineVer, ComputeTypeA, ComputeTypeB, PermuteA, PermuteB >
"Universal" Batched GEMM operation without SplitK support.
- Overview
- This GEMM operation implements the following mathematical equation: C{G,M,N} = C_op(A_op(A{G,M,K}) * B_op(B{G,K,N})) Where A, B are input tensors and C is the output tensor. The A/B/C_op are elementwise operations applied to the A, B, and C tensors, respectively. The "universal" gemm comes with multiple pipelines optimized for different usage scenarios. That's why it's called "universal". It's universal through its design and versatilty.
- Note
- This Kernel implementation currently does not support the SplitK algorithm.
- Template Parameters
-
ALayout A tensor data layout. BLayout B tensor data layout. CLayout C tensor data layout. ADataType A tensor data type. BDataType B tensor data type. CDataType C tensor data type. AccDataType The accumulation data type related to the hardware matrix-multiplication instruction. CShuffleDataType The data type used to store matrix-multiplication results into LDS memory during "CShuffle" data layout optimization. AElementwiseOperation Elementwise operation applied to the A input tensor elements. BElementwiseOperation Elementwise operation applied to the B input tensor elements. CElementwiseOperation Elementwise operation applied to the C output tensor (after GEMM). GemmSpec Determines used "padding" version. BlockSize The number of threads within workgroup. MPerBlock The input/output data tile size in the M dimension. NPerBlock The input/output data tile size in the N dimension. KPerBlock The input data tile size in the K dimension. AK1 The vector load size from global memory for A tensor. BK1 The vector load size from global memory for B tensor. MPerWmma M size of Wave Matrix Multiply Accumulate (WMMA) instruction. NPerWmma N size of Wave Matrix Multiply Accumulate (WMMA) instruction. MRepeat The number of iterations in the M dimension over output tile per wavefront. NRepeat The number of iterations in the N dimension over output tile per wavefront. ABlockTransferThreadClusterLengths_AK0_M_AK1 Spatial thread distribution over the input data. Can be interpreted as the answer to the question, "How many threads can be arranged on each input data axis?" ABlockTransferThreadClusterArrangeOrder The order of thread spatial distribution over the input tensor dimension. Can be interpreted as the answer to the question: "In which order to spread threads through tensor axes?". ABlockTransferSrcAccessOrder The order of accessing input tensor axes. Can be interpreted as the answer to the question "Which dimension to read first? And which next?" etc. ABlockTransferSrcVectorDim The index of axis on which we could do vectorized memory access - the one with contiguous memory. ABlockTransferSrcScalarPerVector The size of vector access instruction - the number of elements accessed per thread per instruction. ABlockTransferDstScalarPerVector_AK1 The size of vectorized store into LDS memory. ABlockLdsExtraM Whether to use padding for LDS or not. With universal GEMM there's no need for padding. BBlockTransferThreadClusterLengths_BK0_N_BK1 Spatial thread distribution over the input data. Can be interpreted as the answer to the question: "How many threads to arrange on each input data axis?" BBlockTransferThreadClusterArrangeOrder The order of thread spatial distribution over the input tensor dimension. Can be interpreted as the answer to the question: "In which order to spread threads through tensor axes?". BBlockTransferSrcAccessOrder he order of accessing input tensor axes. Can be interpreted as the answer to the question "Which dimension to read first? And which next?" etc. BBlockTransferSrcVectorDim The index of axis on which we could do vectorized memory access - the one with contiguous memory. BBlockTransferSrcScalarPerVector The size of vector access instruction - the number of elements accessed per thread per instruction. BBlockTransferDstScalarPerVector_BK1 The size of vectorized store into LDS memory. BBlockLdsExtraN Whether to use padding for LDS or not. With universal GEMM there's no need for padding. CShuffleMRepeatPerShuffle The number of matrix-multiplication instructions results to process per wave per iteration of CShuffle in M dimension. CShuffleNRepeatPerShuffle The number of matrix-multiplication instructions results to process per wave per iteration of CShuffle in N dimension. CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock The spatial thread distribution used for storing data into output tensor across output data layout dimensions. CShuffleBlockTransferScalarPerVector_NPerBlock The size of vectorized memory access. Used when storing data to output tensor. BlkGemmPipeSched The version of blockwise-gemm pipeline scheduler (interwave or intrawave). BlkGemmPipelineVer The version of blockwise-gemm pipeline. ComputeTypeA Data type used for A input of hardware matrix-multiplication instructions. ComputeTypeB Data type used for B input of hardware matrix-multiplication instructions. PermuteA Whether the A input tensor has gridwise-gemm friendly data layout in global memory. Currently not supported! PermuteB Whether the B input tensor has gridwise-gemm friendly data layout in global memory (pre-shuffled). Currently not supported!
Member Typedef Documentation
◆ GridwiseGemm
template<typename ALayout , typename BLayout , typename CLayout , typename ADataType , typename BDataType , typename CDataType , typename AccDataType , typename CShuffleDataType , typename AElementwiseOperation , typename BElementwiseOperation , typename CElementwiseOperation , GemmSpecialization GemmSpec, index_t BlockSize, index_t MPerBlock, index_t NPerBlock, index_t KPerBlock, index_t AK1, index_t BK1, index_t MPerWmma, index_t NPerWmma, index_t MRepeat, index_t NRepeat, typename ABlockTransferThreadClusterLengths_AK0_M_AK1 , typename ABlockTransferThreadClusterArrangeOrder , typename ABlockTransferSrcAccessOrder , index_t ABlockTransferSrcVectorDim, index_t ABlockTransferSrcScalarPerVector, index_t ABlockTransferDstScalarPerVector_AK1, bool ABlockLdsExtraM, typename BBlockTransferThreadClusterLengths_BK0_N_BK1 , typename BBlockTransferThreadClusterArrangeOrder , typename BBlockTransferSrcAccessOrder , index_t BBlockTransferSrcVectorDim, index_t BBlockTransferSrcScalarPerVector, index_t BBlockTransferDstScalarPerVector_BK1, bool BBlockLdsExtraN, index_t CShuffleMRepeatPerShuffle, index_t CShuffleNRepeatPerShuffle, typename CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock , index_t CShuffleBlockTransferScalarPerVector_NPerBlock, BlockGemmPipelineScheduler BlkGemmPipeSched = BlockGemmPipelineScheduler::Intrawave, BlockGemmPipelineVersion BlkGemmPipelineVer = BlockGemmPipelineVersion::v1, typename ComputeTypeA = CDataType, typename ComputeTypeB = ComputeTypeA, bool PermuteA = false, bool PermuteB = false>
| using ck::tensor_operation::device::DeviceBatchedGemm_Wmma_CShuffleV3< ALayout, BLayout, CLayout, ADataType, BDataType, CDataType, AccDataType, CShuffleDataType, AElementwiseOperation, BElementwiseOperation, CElementwiseOperation, GemmSpec, BlockSize, MPerBlock, NPerBlock, KPerBlock, AK1, BK1, MPerWmma, NPerWmma, MRepeat, NRepeat, ABlockTransferThreadClusterLengths_AK0_M_AK1, ABlockTransferThreadClusterArrangeOrder, ABlockTransferSrcAccessOrder, ABlockTransferSrcVectorDim, ABlockTransferSrcScalarPerVector, ABlockTransferDstScalarPerVector_AK1, ABlockLdsExtraM, BBlockTransferThreadClusterLengths_BK0_N_BK1, BBlockTransferThreadClusterArrangeOrder, BBlockTransferSrcAccessOrder, BBlockTransferSrcVectorDim, BBlockTransferSrcScalarPerVector, BBlockTransferDstScalarPerVector_BK1, BBlockLdsExtraN, CShuffleMRepeatPerShuffle, CShuffleNRepeatPerShuffle, CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock, CShuffleBlockTransferScalarPerVector_NPerBlock, BlkGemmPipeSched, BlkGemmPipelineVer, ComputeTypeA, ComputeTypeB, PermuteA, PermuteB >::GridwiseGemm = GridwiseGemm_wmma_cshuffle_v3< ALayout, BLayout, CLayout, ADataType, BDataType, AccDataType, CShuffleDataType, CDataType, AElementwiseOperation, BElementwiseOperation, CElementwiseOperation, GemmSpec, BlockSize, MPerBlock, NPerBlock, KPerBlock, AK1, BK1, MPerWmma, NPerWmma, MRepeat, NRepeat, ABlockTransferThreadClusterLengths_AK0_M_AK1, ABlockTransferThreadClusterArrangeOrder, ABlockTransferSrcAccessOrder, ABlockTransferSrcVectorDim, ABlockTransferSrcScalarPerVector, ABlockTransferDstScalarPerVector_AK1, false, ABlockLdsExtraM, BBlockTransferThreadClusterLengths_BK0_N_BK1, BBlockTransferThreadClusterArrangeOrder, BBlockTransferSrcAccessOrder, BBlockTransferSrcVectorDim, BBlockTransferSrcScalarPerVector, BBlockTransferDstScalarPerVector_BK1, false, BBlockLdsExtraN, CShuffleMRepeatPerShuffle, CShuffleNRepeatPerShuffle, CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock, CShuffleBlockTransferScalarPerVector_NPerBlock, BlkGemmPipeSched, BlkGemmPipelineVer, ComputeTypeA, ComputeTypeB, false, false> |
Member Function Documentation
◆ GetTypeString()
template<typename ALayout , typename BLayout , typename CLayout , typename ADataType , typename BDataType , typename CDataType , typename AccDataType , typename CShuffleDataType , typename AElementwiseOperation , typename BElementwiseOperation , typename CElementwiseOperation , GemmSpecialization GemmSpec, index_t BlockSize, index_t MPerBlock, index_t NPerBlock, index_t KPerBlock, index_t AK1, index_t BK1, index_t MPerWmma, index_t NPerWmma, index_t MRepeat, index_t NRepeat, typename ABlockTransferThreadClusterLengths_AK0_M_AK1 , typename ABlockTransferThreadClusterArrangeOrder , typename ABlockTransferSrcAccessOrder , index_t ABlockTransferSrcVectorDim, index_t ABlockTransferSrcScalarPerVector, index_t ABlockTransferDstScalarPerVector_AK1, bool ABlockLdsExtraM, typename BBlockTransferThreadClusterLengths_BK0_N_BK1 , typename BBlockTransferThreadClusterArrangeOrder , typename BBlockTransferSrcAccessOrder , index_t BBlockTransferSrcVectorDim, index_t BBlockTransferSrcScalarPerVector, index_t BBlockTransferDstScalarPerVector_BK1, bool BBlockLdsExtraN, index_t CShuffleMRepeatPerShuffle, index_t CShuffleNRepeatPerShuffle, typename CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock , index_t CShuffleBlockTransferScalarPerVector_NPerBlock, BlockGemmPipelineScheduler BlkGemmPipeSched = BlockGemmPipelineScheduler::Intrawave, BlockGemmPipelineVersion BlkGemmPipelineVer = BlockGemmPipelineVersion::v1, typename ComputeTypeA = CDataType, typename ComputeTypeB = ComputeTypeA, bool PermuteA = false, bool PermuteB = false>
|
inlineoverridevirtual |
Reimplemented from ck::tensor_operation::device::BaseOperator.
◆ IsSupportedArgument() [1/2]
template<typename ALayout , typename BLayout , typename CLayout , typename ADataType , typename BDataType , typename CDataType , typename AccDataType , typename CShuffleDataType , typename AElementwiseOperation , typename BElementwiseOperation , typename CElementwiseOperation , GemmSpecialization GemmSpec, index_t BlockSize, index_t MPerBlock, index_t NPerBlock, index_t KPerBlock, index_t AK1, index_t BK1, index_t MPerWmma, index_t NPerWmma, index_t MRepeat, index_t NRepeat, typename ABlockTransferThreadClusterLengths_AK0_M_AK1 , typename ABlockTransferThreadClusterArrangeOrder , typename ABlockTransferSrcAccessOrder , index_t ABlockTransferSrcVectorDim, index_t ABlockTransferSrcScalarPerVector, index_t ABlockTransferDstScalarPerVector_AK1, bool ABlockLdsExtraM, typename BBlockTransferThreadClusterLengths_BK0_N_BK1 , typename BBlockTransferThreadClusterArrangeOrder , typename BBlockTransferSrcAccessOrder , index_t BBlockTransferSrcVectorDim, index_t BBlockTransferSrcScalarPerVector, index_t BBlockTransferDstScalarPerVector_BK1, bool BBlockLdsExtraN, index_t CShuffleMRepeatPerShuffle, index_t CShuffleNRepeatPerShuffle, typename CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock , index_t CShuffleBlockTransferScalarPerVector_NPerBlock, BlockGemmPipelineScheduler BlkGemmPipeSched = BlockGemmPipelineScheduler::Intrawave, BlockGemmPipelineVersion BlkGemmPipelineVer = BlockGemmPipelineVersion::v1, typename ComputeTypeA = CDataType, typename ComputeTypeB = ComputeTypeA, bool PermuteA = false, bool PermuteB = false>
|
inlinestatic |
◆ IsSupportedArgument() [2/2]
template<typename ALayout , typename BLayout , typename CLayout , typename ADataType , typename BDataType , typename CDataType , typename AccDataType , typename CShuffleDataType , typename AElementwiseOperation , typename BElementwiseOperation , typename CElementwiseOperation , GemmSpecialization GemmSpec, index_t BlockSize, index_t MPerBlock, index_t NPerBlock, index_t KPerBlock, index_t AK1, index_t BK1, index_t MPerWmma, index_t NPerWmma, index_t MRepeat, index_t NRepeat, typename ABlockTransferThreadClusterLengths_AK0_M_AK1 , typename ABlockTransferThreadClusterArrangeOrder , typename ABlockTransferSrcAccessOrder , index_t ABlockTransferSrcVectorDim, index_t ABlockTransferSrcScalarPerVector, index_t ABlockTransferDstScalarPerVector_AK1, bool ABlockLdsExtraM, typename BBlockTransferThreadClusterLengths_BK0_N_BK1 , typename BBlockTransferThreadClusterArrangeOrder , typename BBlockTransferSrcAccessOrder , index_t BBlockTransferSrcVectorDim, index_t BBlockTransferSrcScalarPerVector, index_t BBlockTransferDstScalarPerVector_BK1, bool BBlockLdsExtraN, index_t CShuffleMRepeatPerShuffle, index_t CShuffleNRepeatPerShuffle, typename CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock , index_t CShuffleBlockTransferScalarPerVector_NPerBlock, BlockGemmPipelineScheduler BlkGemmPipeSched = BlockGemmPipelineScheduler::Intrawave, BlockGemmPipelineVersion BlkGemmPipelineVer = BlockGemmPipelineVersion::v1, typename ComputeTypeA = CDataType, typename ComputeTypeB = ComputeTypeA, bool PermuteA = false, bool PermuteB = false>
|
inlineoverridevirtual |
Reimplemented from ck::tensor_operation::device::BaseOperator.
◆ IsValidCompilationParameter()
template<typename ALayout , typename BLayout , typename CLayout , typename ADataType , typename BDataType , typename CDataType , typename AccDataType , typename CShuffleDataType , typename AElementwiseOperation , typename BElementwiseOperation , typename CElementwiseOperation , GemmSpecialization GemmSpec, index_t BlockSize, index_t MPerBlock, index_t NPerBlock, index_t KPerBlock, index_t AK1, index_t BK1, index_t MPerWmma, index_t NPerWmma, index_t MRepeat, index_t NRepeat, typename ABlockTransferThreadClusterLengths_AK0_M_AK1 , typename ABlockTransferThreadClusterArrangeOrder , typename ABlockTransferSrcAccessOrder , index_t ABlockTransferSrcVectorDim, index_t ABlockTransferSrcScalarPerVector, index_t ABlockTransferDstScalarPerVector_AK1, bool ABlockLdsExtraM, typename BBlockTransferThreadClusterLengths_BK0_N_BK1 , typename BBlockTransferThreadClusterArrangeOrder , typename BBlockTransferSrcAccessOrder , index_t BBlockTransferSrcVectorDim, index_t BBlockTransferSrcScalarPerVector, index_t BBlockTransferDstScalarPerVector_BK1, bool BBlockLdsExtraN, index_t CShuffleMRepeatPerShuffle, index_t CShuffleNRepeatPerShuffle, typename CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock , index_t CShuffleBlockTransferScalarPerVector_NPerBlock, BlockGemmPipelineScheduler BlkGemmPipeSched = BlockGemmPipelineScheduler::Intrawave, BlockGemmPipelineVersion BlkGemmPipelineVer = BlockGemmPipelineVersion::v1, typename ComputeTypeA = CDataType, typename ComputeTypeB = ComputeTypeA, bool PermuteA = false, bool PermuteB = false>
|
inlinestaticconstexpr |
◆ MakeArgument()
template<typename ALayout , typename BLayout , typename CLayout , typename ADataType , typename BDataType , typename CDataType , typename AccDataType , typename CShuffleDataType , typename AElementwiseOperation , typename BElementwiseOperation , typename CElementwiseOperation , GemmSpecialization GemmSpec, index_t BlockSize, index_t MPerBlock, index_t NPerBlock, index_t KPerBlock, index_t AK1, index_t BK1, index_t MPerWmma, index_t NPerWmma, index_t MRepeat, index_t NRepeat, typename ABlockTransferThreadClusterLengths_AK0_M_AK1 , typename ABlockTransferThreadClusterArrangeOrder , typename ABlockTransferSrcAccessOrder , index_t ABlockTransferSrcVectorDim, index_t ABlockTransferSrcScalarPerVector, index_t ABlockTransferDstScalarPerVector_AK1, bool ABlockLdsExtraM, typename BBlockTransferThreadClusterLengths_BK0_N_BK1 , typename BBlockTransferThreadClusterArrangeOrder , typename BBlockTransferSrcAccessOrder , index_t BBlockTransferSrcVectorDim, index_t BBlockTransferSrcScalarPerVector, index_t BBlockTransferDstScalarPerVector_BK1, bool BBlockLdsExtraN, index_t CShuffleMRepeatPerShuffle, index_t CShuffleNRepeatPerShuffle, typename CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock , index_t CShuffleBlockTransferScalarPerVector_NPerBlock, BlockGemmPipelineScheduler BlkGemmPipeSched = BlockGemmPipelineScheduler::Intrawave, BlockGemmPipelineVersion BlkGemmPipelineVer = BlockGemmPipelineVersion::v1, typename ComputeTypeA = CDataType, typename ComputeTypeB = ComputeTypeA, bool PermuteA = false, bool PermuteB = false>
|
inlinestatic |
◆ MakeArgumentPointer()
template<typename ALayout , typename BLayout , typename CLayout , typename ADataType , typename BDataType , typename CDataType , typename AccDataType , typename CShuffleDataType , typename AElementwiseOperation , typename BElementwiseOperation , typename CElementwiseOperation , GemmSpecialization GemmSpec, index_t BlockSize, index_t MPerBlock, index_t NPerBlock, index_t KPerBlock, index_t AK1, index_t BK1, index_t MPerWmma, index_t NPerWmma, index_t MRepeat, index_t NRepeat, typename ABlockTransferThreadClusterLengths_AK0_M_AK1 , typename ABlockTransferThreadClusterArrangeOrder , typename ABlockTransferSrcAccessOrder , index_t ABlockTransferSrcVectorDim, index_t ABlockTransferSrcScalarPerVector, index_t ABlockTransferDstScalarPerVector_AK1, bool ABlockLdsExtraM, typename BBlockTransferThreadClusterLengths_BK0_N_BK1 , typename BBlockTransferThreadClusterArrangeOrder , typename BBlockTransferSrcAccessOrder , index_t BBlockTransferSrcVectorDim, index_t BBlockTransferSrcScalarPerVector, index_t BBlockTransferDstScalarPerVector_BK1, bool BBlockLdsExtraN, index_t CShuffleMRepeatPerShuffle, index_t CShuffleNRepeatPerShuffle, typename CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock , index_t CShuffleBlockTransferScalarPerVector_NPerBlock, BlockGemmPipelineScheduler BlkGemmPipeSched = BlockGemmPipelineScheduler::Intrawave, BlockGemmPipelineVersion BlkGemmPipelineVer = BlockGemmPipelineVersion::v1, typename ComputeTypeA = CDataType, typename ComputeTypeB = ComputeTypeA, bool PermuteA = false, bool PermuteB = false>
|
inlineoverridevirtual |
◆ MakeInvoker()
template<typename ALayout , typename BLayout , typename CLayout , typename ADataType , typename BDataType , typename CDataType , typename AccDataType , typename CShuffleDataType , typename AElementwiseOperation , typename BElementwiseOperation , typename CElementwiseOperation , GemmSpecialization GemmSpec, index_t BlockSize, index_t MPerBlock, index_t NPerBlock, index_t KPerBlock, index_t AK1, index_t BK1, index_t MPerWmma, index_t NPerWmma, index_t MRepeat, index_t NRepeat, typename ABlockTransferThreadClusterLengths_AK0_M_AK1 , typename ABlockTransferThreadClusterArrangeOrder , typename ABlockTransferSrcAccessOrder , index_t ABlockTransferSrcVectorDim, index_t ABlockTransferSrcScalarPerVector, index_t ABlockTransferDstScalarPerVector_AK1, bool ABlockLdsExtraM, typename BBlockTransferThreadClusterLengths_BK0_N_BK1 , typename BBlockTransferThreadClusterArrangeOrder , typename BBlockTransferSrcAccessOrder , index_t BBlockTransferSrcVectorDim, index_t BBlockTransferSrcScalarPerVector, index_t BBlockTransferDstScalarPerVector_BK1, bool BBlockLdsExtraN, index_t CShuffleMRepeatPerShuffle, index_t CShuffleNRepeatPerShuffle, typename CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock , index_t CShuffleBlockTransferScalarPerVector_NPerBlock, BlockGemmPipelineScheduler BlkGemmPipeSched = BlockGemmPipelineScheduler::Intrawave, BlockGemmPipelineVersion BlkGemmPipelineVer = BlockGemmPipelineVersion::v1, typename ComputeTypeA = CDataType, typename ComputeTypeB = ComputeTypeA, bool PermuteA = false, bool PermuteB = false>
|
inlinestatic |
◆ MakeInvokerPointer()
template<typename ALayout , typename BLayout , typename CLayout , typename ADataType , typename BDataType , typename CDataType , typename AccDataType , typename CShuffleDataType , typename AElementwiseOperation , typename BElementwiseOperation , typename CElementwiseOperation , GemmSpecialization GemmSpec, index_t BlockSize, index_t MPerBlock, index_t NPerBlock, index_t KPerBlock, index_t AK1, index_t BK1, index_t MPerWmma, index_t NPerWmma, index_t MRepeat, index_t NRepeat, typename ABlockTransferThreadClusterLengths_AK0_M_AK1 , typename ABlockTransferThreadClusterArrangeOrder , typename ABlockTransferSrcAccessOrder , index_t ABlockTransferSrcVectorDim, index_t ABlockTransferSrcScalarPerVector, index_t ABlockTransferDstScalarPerVector_AK1, bool ABlockLdsExtraM, typename BBlockTransferThreadClusterLengths_BK0_N_BK1 , typename BBlockTransferThreadClusterArrangeOrder , typename BBlockTransferSrcAccessOrder , index_t BBlockTransferSrcVectorDim, index_t BBlockTransferSrcScalarPerVector, index_t BBlockTransferDstScalarPerVector_BK1, bool BBlockLdsExtraN, index_t CShuffleMRepeatPerShuffle, index_t CShuffleNRepeatPerShuffle, typename CShuffleBlockTransferClusterLengths_MBlock_MPerBlock_NBlock_NPerBlock , index_t CShuffleBlockTransferScalarPerVector_NPerBlock, BlockGemmPipelineScheduler BlkGemmPipeSched = BlockGemmPipelineScheduler::Intrawave, BlockGemmPipelineVersion BlkGemmPipelineVer = BlockGemmPipelineVersion::v1, typename ComputeTypeA = CDataType, typename ComputeTypeB = ComputeTypeA, bool PermuteA = false, bool PermuteB = false>
|
inlineoverridevirtual |
The documentation for this struct was generated from the following file:
- /home/docs/checkouts/readthedocs.org/user_builds/advanced-micro-devices-composable-kernel/checkouts/docs-7.0.1/include/ck/tensor_operation/gpu/device/impl/device_batched_gemm_wmma_cshuffle_v3.hpp
